Q'TY/ CTN | N.W./KG | G.W./KG | CUFT | PACKAGE |
---|---|---|---|---|
5 | 12.5 | 13.5 | 0.812 | PLAIN BOX |
* Specifications:
MIN.Free speed:2,200RPM (MAX.FREE SPEED:2,640RPM)
Shank opening: 0.401"
Stroke: 3-3/4"
Bore DIA.: 3/4"(19mm)
Air inlet: 1/4"-NPT
Recommended air pressure: 90 PSI (6.3 BAR)
Recommended air hose size: 3/8"
Air consumption: 4 CFM (28 SCFM)
Sound pressure level: 107 dB(A)
Sound power level: 116 dB(A)
Vibration: 2.9M/SEC^2
