* Gauge diameter: 100mm
* Gauge reading: 70 bar/ 1000psi
* Hose assembly length: 430mm
* Glow plug test adaptors:
    No.1 m10 x p1.0 48.7mm
    No.2 m10 x p1.0 56.7 mm
    No.3 m10 x p1.25 57.7 mm
    No.4 m10 x p1.25 71.7 mm
    No.5 m10 x p1.25 70.7 mm
    No.6 m10 x p1.25 70.7 mm
    No.7 m10 x p1.0 76.7 mm
    No.8 m10 x p1.0 75.7 mm
    No.9 m10 x p1.0 76.7 mm
    No.10 m10 x p1.25 82.7 mm
    No.11 m10 x p1.0 83.7 mm
    No.12 m12 x p1.25 87.7 mm
    No.13 m10 x p1.0 100.7 mm
    No.14 m10 x p1.0 109.7 mm
    No.15 m8 x p1.0 111 mm
    No.16 m10 x p1.25 121.7 mm
    No.17m10 x p1.0 Φ5 131mm
    No.18 Φ5 & Φ16 130mm
    No.19 m10 x p1.25 133.7mm
    No.20 m19 x p1.0 132mm
    No.21 m10 x p1.25 Φ4.1 165mm
    No.22 m10 x p1.0 Φ5 170mm
* Injector test adaptors:
    No.23 m22 x p1.5 end Φ16.5 87mm
    No.24 m24 x p1.5 end Φ9 75mm
    No.25 m20 x p1.5 end Φ9 62mm
    No.26 m24 x p2.0 end Φ13.7
     70mm(without sleeve)
    No.26a m24 x p2.0 end Φ13.7
     70mm(without sleeve)
* Clamp- on injector adaptor(for truck, van, bus, marine, and agricultural vehicles):
    No.27 Φ13.7 x Φ23.7 id: m10 x
     p1.25 41.5mm
    No.28 Φ5.8 x Φ23.7 id: m10 x
     p1.25 30mm
    No.29 Φ16.5 id: m10 x p1.25 30mm
    No.30 Φ13.7 x Φ20.6id: m10 x
     p1.25 41.5mm
    No.31 Φψ6.7 x Φ16.8 id: m10 x
     p1.25 35mm

* Clamp-on spindle:
    No.32 m10 xp1.25 175mm
* Clamp:
    No.33 diameter:13.3 side
     diameter: 8.2 52.5mm
    No.34 diameter:13.3 side
     diameter: 18 64.2mm
    No.35 diameter:13.3 side
     diameter: 24.7 73.1mm
